Self-Braking Magnetic Zipline Trolleys

A self-braking magnetic zipline trolley controls a rider's speed on the line itself, before the landing. It does not stop the rider; that is the job of the end brake. For an operator, that difference decides how steep or long a line can be, how big the landing must be and how consistent every arrival feels.

At a glance

Key takeaways

✓
A magnetic braking trolley reduces and evens out rider speed along the line; an end brake still stops the rider.
✓
Braking force rises with speed, so faster and heavier riders are slowed more than light ones.
✓
How much it brakes depends on the magnet set-up, rider weight, speed and line profile.
✓
The braking energy becomes heat in the trolley housing, not wear on the cable; busy lines need enough trolleys to rotate.
✓
Trolley, end brake and line design are agreed together, early in the design, with the independent inspection body (e.g. TÜV).
The principle

How a magnetic braking trolley works

The trolley carries permanent magnets that move past a conductive part as the wheels turn. This creates eddy currents, which push back against the motion. There are no brake pads and nothing presses on the cable. The braking force follows speed: small at low speed, strong at high speed. The trolley therefore does little on gentle sections and most of its work where the rider would otherwise go fastest.

What determines the braking

Four factors set how much a magnetic trolley slows a rider:

  • Magnet set-up — the configuration chosen for the line: stronger for steep and long lines, lighter for gentle ones.
  • Speed — the faster the rider, the stronger the braking.
  • Rider weight — heavier riders build more speed and are braked harder.
  • Line profile — length, height difference, cable sag and tension.

That is why a magnetic trolley is configured per line, not taken off the shelf. Skywalker sets it in the zipline design, with a predicted arrival speed per rider weight.

For the operator

Where the energy goes

Self-Braking Magnetic Zipline Trolleys: How They Work

Braking turns the rider's speed into heat inside the trolley housing. The cable is not a braking surface, so trolley braking adds no wear to the line. On busy lines, plan enough trolleys to rotate, so each unit cools between runs. Wheels and bearings still wear and are checked on the normal inspection cycle.

What it achieves

✓
Lower peak speeds on steep or long lines.
✓
More consistent arrivals — the gap between light and heavy riders narrows before the landing.
✓
A smaller landing — with less energy left at the end, the braking zone, landing platform and end-brake anchor loads can be smaller.
✓
More freedom in the line — steeper or longer profiles become possible with the same end brake.
Limits

What it does not do

  • It does not stop the rider. A magnetic trolley always works with an end brake, such as a magnetic end brake or a spring brake. See zipline braking systems for the options.
  • It does not return itself to the start. That is what an autonomous bi-directional trolley such as ZipTronik does.

Designing with magnetic trolleys

The trolley choice belongs in the design stage, together with cable tension, end brake and the inspection path. The zipline is designed to EN 15567-1, the trolley carries the manufacturer's load rating and documentation, and the inaugural inspection by an independent body (e.g. TÜV) checks the whole braking concept before opening. For the design side in detail, see how magnetic trolley braking changes zipline design.

Common questions

Magnetic zipline trolley FAQ

What is a self-braking magnetic zipline trolley?

A trolley with a built-in eddy-current brake that reduces and evens out rider speed along the line. It does not stop the rider; an end brake does that.

Does a zipline with magnetic trolleys still need an end brake?

Yes. The trolley controls speed on the line; the end brake stops the rider at the landing. The two are designed as one system.

Do magnetic zipline trolleys get hot?

Yes. Braking energy becomes heat in the trolley housing. Busy lines use enough trolleys to rotate, so each one cools between runs.

Does a magnetic trolley work the same for light and heavy riders?

No, and that is the point: braking rises with speed, so heavier, faster riders are slowed more. That narrows the spread in arrival speed, within the trolley's rated weight range.

Can magnetic trolleys be used on an existing zipline?

Often, if the cable diameter, line profile and end brake suit the trolley. A design check confirms arrival speeds and anchor loads first.
