Magnetic Rope Testing - bridging the gap between adrenaline-filled zipline rides and robust safety standards.
◆ Zipline Operations · Cable Inspection

Magnetic rope testing for ziplines and zipwires

The cable is the one zipline component you cannot fully see. Broken wires and corrosion often start inside the rope, where a visual check does not reach. Magnetic rope testing (MRT) is a non-destructive method that scans the whole cross-section of a steel rope and shows where it has lost strength, so operators can decide on continued use, closer monitoring or replacement.

At a glance

Key takeaways

✓
MRT finds broken wires, corrosion and loss of metallic area, including damage inside the rope.
✓
It is non-destructive: the cable stays in place and in service.
✓
Every MRT session starts with a visual inspection; the scan adds what the eye cannot see.
✓
Results guide one of three decisions: keep using, monitor more closely, or replace.
✓
The testing interval depends on use and environment and is set by a competent person.
The principle

How magnetic rope testing works

An MRT device magnetises a section of the steel rope as it moves along it. In a sound rope, the magnetic field is uniform. Where a wire is broken or the steel has corroded or worn away, the field is disturbed. Sensors in the device pick up these disturbances and record them along the length of the rope.

Magnetic rope testing device on a zipline cable

The recording shows two kinds of findings:

  • Local faults (LF) — short, distinct disturbances such as broken wires or pitting, with their position on the rope.
  • Loss of metallic area (LMA) — a gradual reduction of the steel cross-section caused by wear or corrosion, expressed as a percentage.
The procedure

From visual check to decision

  • Visual inspection — the rope is first checked by eye for surface wear, deformation, kinks and visible corrosion.
  • Scan — the MRT head runs along the full length of the cable and records the signal.
  • Analysis — the data is evaluated to locate faults and estimate their severity.
  • Decision — the rope stays in service, is monitored more closely, or is replaced.
Magnetic rope test results for a zipline cable

Equipment quality matters, but so does the person reading the results. Interpreting an MRT trace takes training and experience with the rope type and the installation, which is why the test is carried out by qualified, certified specialists.

For the operator

Planning MRT into your maintenance cycle

EN 15567-2 requires a documented inspection regime for ropes courses and ziplines, with an annual main inspection. MRT does not replace that inspection; it adds a measured view of the cable that a visual check cannot give. Many operators of busy lines test at least once a year; lines in corrosive environments or with heavy traffic may need shorter intervals. The interval for your line is set by a competent person, based on use, environment and earlier results.

What it brings

✓
Early warning — damage is found before it becomes visible or critical.
✓
Planned replacement — cables are replaced on evidence, not too early and not too late.
✓
Less downtime — repairs and replacements are scheduled outside peak season.
✓
Documentation — each test adds to the cable's inspection record.

Our lifecycle management team combines annual inspections with cable testing and keeps the documentation for your park.

Common questions

Magnetic rope testing FAQ

What does magnetic rope testing detect?

Broken wires, corrosion, wear and loss of metallic area along the full length of a steel rope, including damage inside the rope that a visual check cannot see.

Does the zipline need to be dismantled?

No. MRT is non-destructive and is carried out with the cable in place.

How often should a zipline cable be tested?

It depends on use and environment. Many operators of busy lines test at least once a year; corrosive sites or heavy traffic may need shorter intervals, set by a competent person.

Does MRT replace the annual inspection?

No. The annual main inspection under EN 15567-2 remains; MRT adds a measured assessment of the cable.

What happens if a fault is found?

Significant damage means the rope is replaced. Minor findings may lead to closer monitoring or a shorter test interval.
